Characteristics and parameters of ultrasonic cytometer

Views:0     Author:Site Editor     Publish Time: 2020-08-09      Origin:Site

1. Structural features of ultrasonic cell disruptor:


(1) The ultrasonic probe is made of imported titanium alloy material


(2) High energy efficiency transducer


(3) The amplitude is automatically adjusted to keep the amplitude consistent under different load conditions


(4) Set ultrasonic interval time


(5) Microcomputer control, continuous adjustment of ultrasonic power


(6) Integrated temperature control sample temperature


(7) All soundproof boxes are made of special soundproof materials


2. Technical parameters of ultrasonic cell disruptor:


(1) Operating frequency range: 20~25KHz. Frequency automatic tracking.


(2) Ten sets of routine program data and a set of combined programs can be stored, and there are two working modes: timing and counting.


(3) The combined program can be composed of up to ten sets of conventional programs, and the cyclic or non-cyclic working mode can be selected.


(4) Over-temperature protection and alarm function.


(5) Automatic limit function of ultrasonic output intensity.


(6) Timing mode working time timing: 0~99 hours 59 minutes 59 seconds.


(7) Counting number of ultrasonic work: 0~9999 times.


(8) Ultrasonic time range: 0~99 hours 59 minutes 59 seconds.


(9) Interval time range: 0~99 hours 59 minutes 59 seconds. Gap time=0 means that the ultrasound works continuously.


(10) Temperature control accuracy: ±1℃.


(11) Working voltage: VAC100-240, 50-60Hz.


(12) Working environment: indoor (no humidity, no direct sunlight, no corrosive gas)
